簡易柱状図DXF出力LISPをGeminiで連続出力版にした。

(defun c:kanikan ( / dxf-template target-csv csv-dir files f-name csv-file file-handle
                     header-line label-top label-bottom point-list p-data line-data
                     max-depth grid-bottom final-point-list circle-radius old-osmode
                     ss i ent ent-data txt-val save-path acad-obj doc model-space)
  (vl-load-com)
  (princ "\n--- 地質調査グラフ一括作成モード開始 ---")

  ;; --- 基本設定 ---
  (setq circle-radius 20.0)
  (setq old-osmode (getvar "OSMODE"))
  (setvar "OSMODE" 0)
  (setvar "CMDECHO" 0)

  (setq acad-obj (vlax-get-acad-object)
        doc      (vla-get-activedocument acad-obj)
        model-space (vla-get-modelspace doc))

  ;; 1. テンプレートDXFの選択
  (setq dxf-template (getfiled "ベースのDXFファイルを選択" "" "dxf" 4))
  (if (not (and dxf-template (findfile dxf-template)))
    (progn (princ "\nDXFテンプレートが選択されませんでした。") (exit))
  )

  ;; 2. CSVフォルダの取得
  (setq target-csv (getfiled "処理したいフォルダ内のCSVをどれか1つ選択" "" "csv" 4))
  (if (and target-csv (setq csv-dir (vl-filename-directory target-csv)))
    (progn
      (setq files (vl-directory-files csv-dir "*.csv" 1))
      (princ (strcat "\n合計 " (itoa (length files)) " 個のファイルを処理します..."))

      ;; --- メインループ開始 ---
      (foreach f-name files
        (setq csv-file (strcat csv-dir "\\" f-name))
        (setq file-handle (open csv-file "r"))

        (if file-handle
          (progn
            ;; 図面を全削除して初期化
            (vlax-for obj model-space (vla-delete obj))
            (vla-purgeall doc)

            ;; テンプレート挿入
            (command "_.-INSERT" (strcat "*" dxf-template) "0,0" "1" "0")

            ;; 1行目：ラベル分離
            (setq header-line (read-line file-handle))
            (if (setq pos (vl-string-search "," header-line))
              (setq label-top (substr header-line 1 pos)
                    label-bottom (substr header-line (+ 2 pos)))
              (setq label-top header-line label-bottom "")
            )

            ;; 2行目以降：データ取得
            (setq point-list '() max-depth 0.0)
            (while (setq line-data (read-line file-handle))
              (setq line-data (vl-string-translate "," " " line-data))
              (setq p-data (read (strcat "(" line-data ")")))
              (if (and (listp p-data) (>= (length p-data) 2))
                (progn
                  (setq point-list (append point-list (list p-data)))
                  (if (> (float (cadr p-data)) max-depth) (setq max-depth (float (cadr p-data))))
                )
              )
            )
            (close file-handle)

            ;; グリッド作成
            (setq grid-bottom (* (+ max-depth 500.0) -1.0))
            (foreach x-val '(0 10 20 30 40 50)
              (command "_LINE" (list (* x-val 40.0) 0.0) (list (* x-val 40.0) grid-bottom) "")
            )
            (command "_LINE" (list 0.0 0.0) (list 2000.0 0.0) "")
            (command "_LINE" (list 0.0 grid-bottom) (list 2000.0 grid-bottom) "")

            ;; グラフ作図
            (if point-list
              (progn
                (setq final-point-list '())
                (foreach pt point-list
                  (setq final-point-list (append final-point-list (list (list (* (car pt) 40.0) (* (cadr pt) -1.0)))))
                )
                (command "_PLINE") (foreach pt final-point-list (command pt)) (command "")
                (foreach pt final-point-list (command "_CIRCLE" pt circle-radius))

                ;; ラベル置換
                (setq ss (ssget "X" '((0 . "TEXT,MTEXT"))))
                (if ss
                  (progn
                    (setq i 0)
                    (repeat (sslength ss)
                      (setq ent (ssname ss i)
                            ent-data (entget ent)
                            txt-val (cdr (assoc 1 ent-data)))
                      (cond
                        ((vl-string-search "No." txt-val)
                         (setq ent-data (subst (cons 1 label-top) (assoc 1 ent-data) ent-data)))
                        ((vl-string-search "m" txt-val)
                         (setq ent-data (subst (cons 1 label-bottom) (assoc 1 ent-data) ent-data)))
                      )
                      (entmod ent-data)
                      (setq i (1+ i))
                    )
                  )
                )

                ;; DXF書き出し
                (setq save-path (strcat csv-dir "\\" (vl-filename-base f-name) ".dxf"))
                (if (findfile save-path) (vl-file-delete save-path))
                (setvar "FILEDIA" 0)
                (command "_DXFOUT" save-path "V" "2000" "16")
                (setvar "FILEDIA" 1)
                (princ (strcat "\n完了: " save-path))
              )
            )
          )
        )
      )
    )
  )

  (setvar "OSMODE" old-osmode)
  (setvar "CMDECHO" 1)
  (princ "\n--- 全てのCSV処理が完了しました ---")
  (princ)
)
